Product Details
Place of Origin: Zhejiang, China
Brand Name: Spark
Certification: CE, SGS, ROHS
Model Number: JY-BAA28TYPE4S-27075
Payment & Shipping Terms
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: In Carton Box
Delivery Time: 2-5 work days
Payment Terms: T/T, Western Union, MoneyGram, Paypal
Supply Ability: 100000pcs/per week
Material: |
PC |
Beam Angle: |
100*130 Degree |
Efficiency: |
93% |
LED Chips: |
2*2pcs 3030 / 1pc 5050 |
Accessory: |
AL PCB+ Silicone Gasket |
Application: |
Shoebox Lighting |
Dimension: |
270*75mm |
Material: |
PC |
Beam Angle: |
100*130 Degree |
Efficiency: |
93% |
LED Chips: |
2*2pcs 3030 / 1pc 5050 |
Accessory: |
AL PCB+ Silicone Gasket |
Application: |
Shoebox Lighting |
Dimension: |
270*75mm |
TYPE4-S 100*130 Degree LED Street Light Lens With 2*2PCS 3030 / 1PC 5050 LED
A simple Lens consists of a single piece of material, while a compound Lens consists of several
simple lenses (elements), usually along a common axis.
A Lens is a Transmissive Optical Device that affects the focus of a light beam through refraction.
|
Part Number |
JY-BAA28TYPE4S-27075 |
|
Beam angle |
100*130 Degree |
|
Dimension |
270*75mm |
|
Lens Material |
PMMA / PC |
|
Transmittance |
93% |
|
Working Temperature |
Lens ≤ 90℃ |
|
Application |
Shoebox Lighting |
Delivery and Shipping:
| Trade Terms | EXW , FOB , CNF , CIF |
| Payment Terms | T/T , PayPal , Western Union, Moneygram |
| Lead Time | 1-2 working days for samples order, 5-7 working days for bulk order |
| Shipment Terms | By Sea, By Air, By Express like DHL, Fedex, UPS, TNT, etc |
LED applications that require more focused light often use a secondary optic that is placed over the
LED, which internally reflects light into a spot, medium spot, wide spot or elliptical spot pattern.
Most optics are cone shaped and need an optic holder to hold the lens in place over the LED. The
lens itself clips securely into the holder, but the holder does need to be externally adhered.
Lens holders provide a mechanical cut-off shield and can also be used to enhance performance.
They are also much easier to install than a stand-alone lens.
LED Lens' Drawing:
IES:
Gasket's Size:
PCB Board's Size:
